ATM-8-30 КОРПУС СЕРВОДВИГ.

Код детали Описание Кол-во на автомобиле
1 22748P24J00 PIPE, 8X220 1
2 24271PRP000 SHAFT, SHIFT FORK 1
3 24630PRP000 ARM COMP., CHANGE DETENT 1
4 24635PRP000 COLLAR, CHANGE DETENT ARM 1
5 27263PX3000 SEAT, VALVE SPRING 1
6 27405RCTA01 BODY SUB ASSY., SERVO 1
6 27405RCTA02 BODY SUB ASSY., SERVO 1
7 27412PRP010 PLATE, SERVO SEPARATING 1
8 27561PRP000 PISTON, LOW ACCUMULATOR 1
9 27562PRP000 SPRING A, LOW ACCUMULATOR 1
10 27564PRP000 SPRING B, LOW ACCUMULATOR 1
11 27572PRP000 PISTON, SECOND ACCUMULATOR 1
12 27574PRP000 PISTON, THIRD ACCUMULATOR 1
13 27580PRPJ00 COVER, SERVO ACCUMULATOR 1
14 27581RCLA00 SPRING A, SECOND ACCUMULATOR 1
15 27583PRP000 SPRING, THIRD ACCUMULATOR 1
16 27584RCLA00 SPRING B, SECOND ACCUMULATOR 1
17 28400RCT003 SOLENOID ASSY. A 3
18 28500RCT003 SOLENOID ASSY. B 2
19 90001PRP000 BOLT, FLANGE, 6X30 2
20 90433PRP000 WASHER, LOCK, 6MM 1
21 91301P6H003 Кольцо уплотнительное 7,6X1,9 5
22 91302P6H003 O-RING, 9.6X1.9 (KEIHIN) 5
23 91321PF4004 O-RING, 18.3X2.4 (NOK) 1
24 91331PC9003 O-RING, 21.2X2.4 (ARAI) 1
25 91331PL5J00 O-RING, 20.2X2.4 (NOK) 1
26 91344580000 O-RING, 31X2.7 (ARAI) 1
27 93301060400H BOLT, HEX., 6X40 1
28 9430108140 Штифт 8X14 2
29 957010601608 Болт 6X16 3
30 957010602508 Болт 6X25 1
31 957010605508 BOLT, FLANGE, 6X55 7
32 957010607008 BOLT, FLANGE, 6X70 3
