Код детали |
Описание |
Кол-во на автомобиле |
1 |
22533PX4010 |
SEAT, RETURN SPRING |
2 |
2 |
22536PRP013 |
SPRING, CLUTCH WAVE |
2 |
3 |
22541PX4004 |
SPRING, CLUTCH RETURN (SANKO) |
2 |
3 |
22541P0Y005 |
SPRING, CLUTCH RETURN (JAYTEC) |
2 |
4 |
22546RCLA01 |
DISK, CLUTCH |
8 |
4 |
22546RCLA02 |
DISK, CLUTCH |
8 |
5 |
22586R90003 |
PLATE, CLUTCH END (6) (2.6MM) |
2 |
5 |
22585R91003 |
PLATE, CLUTCH END (5) (2.5MM) |
2 |
5 |
22585R90003 |
PLATE, CLUTCH END (5) (2.5MM) |
2 |
5 |
22584R91003 |
PLATE, CLUTCH END (4) (2.4MM) |
2 |
5 |
22584R90003 |
PLATE, CLUTCH END (4) (2.4MM) |
2 |
5 |
22586R91003 |
PLATE, CLUTCH END (6) (2.6MM) |
2 |
5 |
22587R90003 |
PLATE, CLUTCH END (7) (2.7MM) |
2 |
5 |
22587R91003 |
PLATE, CLUTCH END (7) (2.7MM) |
2 |
5 |
22588R90003 |
PLATE, CLUTCH END (8) (2.8MM) |
2 |
5 |
22588R91003 |
PLATE, CLUTCH END (8) (2.8MM) |
2 |
5 |
22589R90003 |
PLATE, CLUTCH END (9) (2.9MM) |
2 |
5 |
22589R91003 |
PLATE, CLUTCH END (9) (2.9MM) |
2 |
5 |
22583R91003 |
PLATE, CLUTCH END (3) (2.3MM) |
2 |
5 |
22583R90003 |
PLATE, CLUTCH END (3) (2.3MM) |
2 |
5 |
22582R91003 |
PLATE, CLUTCH END (2) (2.2MM) |
2 |
5 |
22581RCL003 |
PLATE, CLUTCH END (1) (2.1MM) |
2 |
5 |
22582RCL003 |
PLATE, CLUTCH END (2) (2.2MM) |
2 |
5 |
22583RCL003 |
PLATE, CLUTCH END (3) (2.3MM) |
2 |
5 |
22584RCL003 |
PLATE, CLUTCH END (4) (2.4MM) |
2 |
5 |
22585RCL003 |
PLATE, CLUTCH END (5) (2.5MM) |
2 |
5 |
22586RCL003 |
PLATE, CLUTCH END (6) (2.6MM) |
2 |
5 |
22587RCL003 |
PLATE, CLUTCH END (7) (2.7MM) |
2 |
5 |
22588RCL003 |
PLATE, CLUTCH END (8) (2.8MM) |
2 |
5 |
22589RCL003 |
PLATE, CLUTCH END (9) (2.9MM) |
2 |
5 |
22581R90003 |
PLATE, CLUTCH END (1) (2.1MM) |
2 |
5 |
22581R91003 |
PLATE, CLUTCH END (1) (2.1MM) |
2 |
5 |
22582R90003 |
PLATE, CLUTCH END (2) (2.2MM) |
2 |
6 |
22651RFK003 |
GUIDE COMP., CLUTCH (4-5) |
1 |
7 |
22653R91003 |
PLATE, CLUTCH WAVE (2.0MM) |
8 |
7 |
22653R90003 |
PLATE, CLUTCH WAVE (2.0MM) |
8 |
7 |
22653RCLA01 |
PLATE, CLUTCH WAVE (2.0MM) |
8 |
8 |
22680RCR003 |
PISTON COMP., CLUTCH |
2 |
9 |
90603PX4000 |
CIRCLIP, EXTERNAL, 47MM |
2 |
10 |
90605P7T003 |
RING, SNAP, 133MM |
2 |
11 |
91302PX4004 |
Кольцо уплотнительное заглушки блока цилиндров 46.8X2.2 |
2 |
12 |
91303PX4004 |
O-RING, 114X2.2(NOK) |
2 |
