B-41 ЗАДНЕЕ СИДЕНЬЕ

Код детали Описание Кол-во на автомобиле
1 04810SB3000 Крепеж обшивки сиденья комплект 30 шт 1
1 04810SB3R00 C CLIP SET, TRIM FASTENER (100 PIECES) 1
2 78182SA0000 CLIP, RR. SEAT PIN 1
3 82121SEAJ21ZA COVER, R. RR. SEATBACK TRIM *NH167L* 1
4 82126SEA003 FRAME COMP., R. RR. SEATBACK 1
5 82127SEAJ01 PAD COMP., R. RR. SEATBACK 1
6 82127S5A003ZC GUIDE, RR. CENTER SEATBELT *NH167L* 1
7 82129SM4A00 COLLAR C 2
8 82131SEAE21ZA COVER, RR. SEAT CUSHION TRIM *NH167L* 1
9 82132SEAJ01 PAD & FRAME COMP., RR. SEAT CUSHION 1
10 82137S84A01 CLIP, RR. SEAT CUSHION 2
11 82140SEAE21ZA HEADREST ASSY., RR. SEAT *NH167L* 2
12 82143SDAA01ZA GUIDE, HEADREST FREE *NH167L* 3
13 82144SDAA01ZA GUIDE COMP., HEADREST LOCK *NH167L* 3
14 82151SEAE21ZA COVER, R. RR. SIDE SEATBACK TRIM *NH167L* 1
15 82152SEAJ01 PAD & FRAME COMP., R. RR. SEATBACK SIDE 1
16 82160SEAE21ZA HEADREST ASSY., RR. SEAT CENTER *NH167L* 1
17 82180SEAE21ZA ARMREST ASSY., RR. SEAT *NH167L* 1
18 82183SDAA11ZA HOLDER, RR. ARMREST CUP *NH167L* 1
19 82220SEAE02 LOCK ASSY., R. RR. SEAT 1
20 82290SDAA01 BRACKET COMP., R. SEAT PIVOT 1
21 82291S04000 COVER, RR. CENTER PIVOT 1
22 82292S04000 COLLAR, RR. CENTER SEAT PIVOT 1
23 82295SEA003 BRACKET COMP., CENTER SEAT PIVOT 1
24 82521SEAE21ZA COVER, L. RR. SEATBACK TRIM *NH167L* 1
25 82526SEAE01 FRAME COMP., L. RR. SEATBACK 1
26 82527SEAE01 PAD COMP., L. RR. SEATBACK 1
27 82528SEAE21ZA BOARD ASSY., RR. BACK *NH167L* 1
28 82551SEAE21ZA COVER, L. RR. SIDE SEATBACK TRIM *NH167L* 1
29 82552SEAJ01 PAD & FRAME COMP., L. RR. SEATBACK SIDE 1
30 82620SEAE02 LOCK ASSY., L. RR. SEAT 1
31 82690SDAA01 BRACKET COMP., L. SEAT PIVOT 1
32 90003692000 BOLT, FLANGE, 6X16 1
33 90139S6A003 BOLT, FLANGE, 8X35 1
34 90140SA5000 BOLT, SPLASH GUARD 2
35 934030601608 Болт 6X16 4
36 934030801608 Болт 8X16 5
37 9350006018 SCREW, PAN, 6X18 1
