B-4 ТОПЛИВОПРОВОД

Код детали Описание Кол-во на автомобиле
1 16050SEAG00 Трубка топливная 1
2 16722RBAG01 HOSE COMP. B, FUEL FEED 1
5 16723RBAG00 BRACKET COMP., FUEL FEED HOSE 1
6 16725RAC003 CLAMP, FUEL HOSE (NATURAL) 1
7 16725RBAJ00 COVER A, FUEL CONNECTOR 1
8 16726RBAJ00 COVER B, FUEL CONNECTOR 1
9 16727PND004 Хомут топливной трубки 1
11 17711S0X004 RETAINER (WHITE) (SANOH) 1
12 17717SDAG03 HOSE ASSY., FUEL PURGE 1
14 17718SEA020 STAY, PURGE HOSE 1
17 17762SDAA00 STAY B, FUEL PIPE 1
18 17763SDAA01 STAY C, FUEL PIPE 1
19 17764SDAA01 STAY D, FUEL PIPE 1
20 36166PAAA01 Переходник топливных трубок 1
21 90361SV4003 NUT, PAINT CUTTING, 6MM 2
22 91405SDA000 CLAMP, TUBE(D10.5) 1
23 91407SDB000 CLAMP, TUBE (D12.5) 3
24 91594SDCE00 RUBBER A, FUEL PIPE INSULATOR 1
25 91595SDCE00 RUBBER B, FUEL PIPE INSULATOR 1
26 91595S7A931 CLAMP A, FUEL PIPE 1
27 91599SDCE00 RUBBER E, FUEL PIPE INSULATOR 1
28 91599S7A931 CLAMP B, FUEL PIPE 3
29 934030601208 BOLT-WASHER, 6X12 1
30 934030601604 Болт 6X16 2
31 957010601408 Болт 6X14 2
32 17761SDAA00 STAY A, FUEL PIPE 1
