B-13-10 БЛОК УПРАВЛЕНИЯ (КАБИНА) (ЛЕВОСТОРОННИЙ РУЛЬ)

Код детали Описание Кол-во на автомобиле
1 33136SEAG01 SENSOR ASSY., HEADLIGHT ADJUSTER FR. 0
2 33137SEAG51 CONTROL UNIT, AUTO LEVELING ELECTRONIC 0
3 33143S1AG01 NUT, SPECIAL, 6MM 0
4 33146SEAG01 SENSOR ASSY., HEADLIGHT ADJUSTER RR. 0
6 36701SEAG00 BRACKET, UNIT 1
7 37820RBBE57 CONTROL MODULE, ENGINE (REWRITABLE) 1
8 37850PPD911 DRIVER UNIT, DRIVE BY WIRE 1
9 37851RCAA00 BRACKET COMP., DRIVE BY WIRE DRIVER 1
10 37852RBB000 SUB HARNESS, DRIVE BY WIRE DRIVER 1
11 38200SEAG24 BOX ASSY., FUSE 1
12 38300SDCA02 RELAY ASSY., TURN SIGNAL & HAZARD(DENSO) 1
12 38300SHJA04 Реле указателя поворотов 1
13 38310SEAG01 RELAY, CLEANER CONTROL 0
14 38970SJA003 SENSOR ASSY., RAIN 1
15 38971S3VA01 CLIP, SPRING 2
16 38980SEA000ZA Крышка датчика дождя 1
17 39720SEAE02 IMOES UNIT 1
18 39721SEAG00 BRACKET, IMOES UNIT 1
19 39770SEAE01 HFT UNIT (BLUETOOTH) 1
20 39794SDAA05 Реле Micro ISO Mitsuba 9
20 39794SDAA02 RELAY ASSY., POWER (MICRO ISO) (DENSO) 9
21 39794SDA003 RELAY ASSY., FUEL PUMP (MITSUBA) 1
21 39794SDA004 Реле топливного насоса DENSO 1
22 39794SDA901 RELAY ASSY., ENGINE CONTROL MODULE (MITSUBA) 2
22 39794SDA902 Реле DENSO 2
24 39850SEAG51 CONTROL UNIT, AUTO LIGHT 0
25 39860SEAE51 SENSOR ASSY., AUTO LIGHT 0
26 39960SDAA01 SENSOR ASSY., YAW & G 1
27 39961SEA000 BRACKET, YAW & G SENSOR 1
28 39962SEA000 COVER, YAW & G SENSOR 1
29 90148SE0003 BOLT, EARTH, 6X16 (WASHER 12.5MM) (ZN) 5
30 91507P01003 CLIP B, HARNESS BAND (DARK BROWN) (129.4MM) 1
31 91533S04003 CLIP, COUPLER (NATURAL) 1
32 91558ST5003 CLIP, HARNESS BAND (NATURAL) (135MM) (7MM HOLE) 1
33 91640SM4003 GROMMET, SCREW, 4MM 2
34 934020601608 Болт 6X16 0
35 934030601608 BOLT-WASHER, 6X16 2
35 934030601608 BOLT-WASHER, 6X16 0
36 934050602008 Болт 2
37 9391314480 Винт 4X16 2
38 957010601000 Болт 1
39 957010601208 BOLT, FLANGE, 6X12 2
39 957010601208 BOLT, FLANGE, 6X12 0
40 957010601608 Болт 6X16 2
41 957010602508 Болт 6X25 2
42 9820040750 Предохранитель mini 7.5A 7
43 9820041000 Предохранитель mini 10A 5
44 9820041500 Предохранитель mini 15A 5
45 9820042000 Предохранитель mini 20A 12
46 9820043000 Предохранитель mini 30A 1
