B-47-1 ПОДВЕСКИ ДВИГАТЕЛЯ (AT)

Код детали Описание Кол-во на автомобиле
1 36536RAAA50 STAY A, AIR FLOW SENSOR 1
2 50610SDAA01 BRACKET, RR. ENGINE MOUNTING 1
3 50620SDAA01 BRACKET, SIDE ENGINE MOUNTING 1
4 50630SDAA02 BRACKET, FR. ENGINE MOUNTING 1
5 50670SEAE01 BRACKET, TRANSMISSION UPPER MOUNT 1
6 50810SDAE01 Опора двигателя задняя AT 1
7 50815SDAA01 STOPPER, ENGINE RR. MOUNTING 1
8 50820SEAE01 Опора двигателя правая 1
9 50830SDAE01 Опора двигателя передняя 1
10 50835SDAA02 STOPPER, ENGINE FR. MOUNT(AT) 1
11 50850SDAA00 Опора трансмиссии передняя, нижняя 1
12 50860SDAA02 Опора трансмиссии задняя, нижняя 1
13 50870SEAE01 Опора трансмиссии верхняя 1
14 50875SEAE02 PLATE, TRANSMISSION UPPER MOUNT STOPPER 1
15 50933SZ3003 CLIP, ACCUMULATOR PIPE 2
16 50942SEAE00 PIPE 1
17 50943SEAE00 TUBE 1
18 50946SEAE00 STAY D, ELECTRONIC CONTROL MOUNT PIPE 1
19 50947SDAA01 STAY A, ELECTRONIC CONTROL MOUNT TUBE 1
20 90161SDAA01 BOLT, FLANGE, 12X45 1
21 90162SDAA00 BOLT, SPECIAL, 10X34 1
22 90163SDAA01 BOLT, FLANGE, 10X35 2
23 90163S5A000 BOLT, FLANGE, 10X20 8
24 90165SDAA00 BOLT, FLANGE, 12X45 3
25 90166SDAA00 BOLT, FLANGE, 12X80 1
26 90167SDAA00 BOLT, FLANGE, 12X85 2
27 90168SDAA00 BOLT, FLANGE, 12X125 2
28 90169SDAA01 BOLT, FLANGE, 10X62 1
29 90178SDAA00 BOLT, FLANGE, 10X16 2
30 90371S87A00 Гайка 10MM 4
31 9405012080 Гайка 12mm 4
32 957010601008 BOLT, FLANGE, 6X10 1
33 957010601208 Болт 6X12 1
34 957011002008 Болт 10X20 3
35 957011004508 BOLT, FLANGE, 10X45 3
36 957011203508 BOLT, FLANGE, 12X35 2
37 957011205008 BOLT, FLANGE, 12X50 1
38 957011206508 BOLT, FLANGE, 12X65 2
39 957011207508 BOLT, FLANGE, 12X75 1
