E-7 ЖГУТ ПРОВОДОВ ДВИГАТЕЛЯ (ЛЕВОСТОРОННИЙ РУЛЬ)

Код детали Описание Кол-во на автомобиле
1 32110RBBG52 HARNESS, ENGINE WIRE 1
2 32111RBBG52 SUB CORD, STARTER 1
3 32113PLD003 COLLAR, HARNESS GROMMET 2
4 32117P65003 Фиксатор 1
5 32117RTA003 HOLDER, CORRUGATED (BLACK) (15U) 1
6 32118P72003 HOLDER, CORRUGATED (DARK GREEN) (19MM) 3
7 32121RAAA00 HOLDER A, ENGINE HARNESS 1
8 32122RAAA00 HOLDER B, ENGINE HARNESS 1
9 32123RAAA00 HOLDER C, ENGINE HARNESS 1
10 32124RAAA01 HOLDER D, ENGINE HARNESS 1
11 32125RBA000 Кронштейн жгута проводов 1
12 32418RBG300 COVER, BATTERY TERMINAL 1
13 32601SK7900 BOLT, BATTERY TERMINAL 1
14 32602SK7900 NUT, BATTERY TERMINAL 1
15 32741RAAA00 STAY E, ENGINE HARNESS 1
16 32745RAAA00 STAY L, ENGINE HARNESS 1
17 32746RAAA01 STAY C, ENGINE HARNESS 1
18 38182SEAE01 COVER, RELAY BLOCK UPPER (FUSE) 1
19 90028RAA003 BOLT, SPECIAL, 6X18.2 1
20 90051PNA000 BOLT, SPECIAL, 6X28 1
21 90337SJ4003 NUT, A.L.B. 1
22 91506RTA003 CLIP A, HARNESS BAND (DARK VIOLET) (129.4MM) 8
23 91507RTA003 CLIP B, HARNESS BAND (DARK GREEN) (129.4MM) 6
24 91509RRA003 CLIP D, WIRE HARNESS (BLACK) (135.4MM) 1
25 91551PNA003 BAND, WIRE HARNESS (BLACK) (172MM) 1
26 91551SF4003 BAND, WIRE HARNESS (BROWN) (110MM) 1
27 91556PDFE01 Хомут 2
28 91558P8CA01 CLIP, HARNESS BAND (VIOLET) (150MM) 2
29 91558ST5003 CLIP, HARNESS BAND (NATURAL) (135MM) (7MM HOLE) 4
30 91559PAAA01 CLIP, HARNESS BAND(GRAY) (150MM) 1
31 91559RCAA01 CLIP, HARNESS BAND(DARK GRAY) (150MM) 2
32 934030601208 BOLT-WASHER, 6X12 2
33 957010601608 Болт 6X16 1
34 9820042000 Предохранитель mini 20A 1
