E-3-1 ВПУСКНОЙ КОЛЛЕКТОР (2.4L)

Код детали Описание Кол-во на автомобиле
1 17110RBB000 MANIFOLD COMP., INTAKE 1
2 17115RAAA01 Прокладка впускного коллектора 1
3 17132RACU00 STAY COMP., INTAKE MANIFOLD 1
4 17205PC6000 CLAMP, TUBE, 7.5X2 1
5 37830PNC003 Датчик MAP 1
6 37835PGKA01 O-RING 1
7 46406SEAA50 STAY A, MASTER POWER TUBE 1
8 50931SDAA01 VALVE ASSY., ELECTRONIC CONTROL MOUNTING SOLENOID 1
9 50932SDAA01 STAY, ELECTRONIC CONTROL MOUNT SOLENOID VALVE 1
10 50933SDAA01 TUBE A, ELECTRONIC CONTROL MOUNT SOLENOID 1
11 50934SDAA01 TUBE B, ELECTRONIC CONTROL MOUNT SOLENOID 1
12 50934SW5A80 CLIP, ACCUMULATOR TUBE 3
13 50948SDAA00 STAY B, ELECTRONIC CONTROL MOUNT TUBE 1
14 50949SDAA00 STAY C, ELECTRONIC CONTROL MOUNT TUBE 1
15 92900080220B BOLT, STUD, 8X22 1
16 92900080501B BOLT, STUD, 8X50 2
17 938920501007 SCREW-WASHER, 5X10 1
18 938920502008 SCREW-WASHER, 5X20 1
19 9405008080 Гайка 8 MM 3
20 957010601208 Болт 6X12 2
21 957010601408 Болт 6X14 1
22 957010601608 Болт 6X16 1
23 957010802008 Болт 1
24 957010803508 BOLT, FLANGE, 8X35 3
