E-16 КОЛЕНВАЛ/ПОРШЕНЬ

Код детали Описание Кол-во на автомобиле
1 13010RBB010 PISTON SET A (STD.) 4
1 13020RBB010 PISTON SET B (STD.) 4
1 13030RBB010 PISTON SET (OS 0.25) 0
2 13021RBB006 RING SET, PISTON (OS 0.25) (NIPPON) 0
2 13021RBB004 RING SET, PISTON (OS 0.25) (RIKEN) 0
2 13011RBB006 Кольца поршневые, к-т 4
2 13011RBB004 RING SET, PISTON (STD.) (RIKEN) 4
3 13111PNA010 PIN, PISTON 4
4 13115PRBA00 CLIP, PISTON PIN 8
5 13204RBB004 Болт 8
6 13210RBBA00 Шатун 4
7 13212RBB003 Вкладыш шатунный ЧЁРНЫЙ 8
7 13217RBB003 Вкладыш коленвала шатунный RED 8
7 13216RBB003 BEARING F, CONNECTING ROD (PINK) (DAIDO) 8
7 13215RBB003 Вкладыш коленвала шатунный ЖЕЛТЫЙ  8
7 13214RBB003 Вкладыш шатунный D, GREEN 8
7 13213RBB003 BEARING C, CONNECTING ROD (BROWN) (DAIDO) 8
8 13310RBB010 CRANKSHAFT COMP. 1
9 13327PRBA01 BEARING G, MAIN UPPER (RED) (DAIDO) 5
9 13326PRBA01 BEARING F, MAIN UPPER (PINK) (DAIDO) 5
9 13325PRBA01 BEARING E, MAIN UPPER (YELLOW) (DAIDO) 5
9 13324PRBA01 BEARING D, MAIN UPPER (GREEN) (DAIDO) 5
9 13323PRBA01 BEARING C, MAIN UPPER (BROWN) (DAIDO) 5
9 13322PRBA01 BEARING B, MAIN UPPER (BLACK) (DAIDO) 5
10 13331PNA004 Полукольца коленвала 2
11 13347PRBA01 BEARING G, MAIN LOWER (RED) (DAIDO) 5
11 13346PRBA01 BEARING F, MAIN LOWER (PINK) (DAIDO) 5
11 13345PRBA01 BEARING E, MAIN LOWER (YELLOW) (DAIDO) 5
11 13344PRBA01 BEARING D, MAIN LOWER (GREEN) (DAIDO) 5
11 13343PRBA01 BEARING C, MAIN LOWER (BROWN) (DAIDO) 5
11 13342PRBA01 BEARING B, MAIN LOWER (BLACK) (DAIDO) 5
12 13620RAAA02 Шестерня коленвала 1
13 13622PNA003 PLATE, CRANK PULSER 1
14 13810PNA013 PULLEY COMP., CRANKSHAFT 1
15 90017PCX013 Болт шкива коленвала 16X49 1
16 90703PDEE00 DOWEL PIN, 11X12 8
17 90704PNA000 Шпонка 1
